Main Features

· Voltage measurement accuracy: 0.05%+0.05%F.S.

· Current measurement accuracy: 0.1%+0.1%F.S.

· CV, CC, CP, CR three ranges, wide measurement range

· Supporting SEQ test, discharge test, charge test, OCP/OPP test and short-circuit simulation

· 8 operation modes: CC, CV, CP, CR, CV+CC, CR+CC, CV+CR, CP+CC

· Programmable protection, OCP, OCP, OPP, OTP and reverse connection detection

· Time measurement, rise/fall time measurement accuracy: 1μs

· Supporting 100 groups of parameters to be saved when powered off and easy to recall

· Supporting MPPT maximum power point tracking function

· Equivalent DC internal resistance (DCIR) test (optional)

· LAN/RS232/CAN as standard interface, GPIB as optional interface​
