Main Features

· Power specification: 150W/4CH, 300W/2CH

· Integrates 4 channels in 2U height and half 19 inch width chassis, parallel connection supportable between channels

· Support LED simulation function, LED power supply real load test

· Support CC, CV, CR, CP dynamic test, CC dynamic up to 30kHz

· Voltage, current, resistance, power dual range, wide measurement range

· Support sequence test, automatic test, Von/Voff, short-circuit simulation, ripple measurement functions

· Support OCP/OVP/OPP test, load effect test

· Support USB PD2.0/PD3.0/PD3.1/QC 2.0/QC 3.0/QC 4.0+/PE+/PE+2.0/FCP/SCP/AFC/VOOC protocols

· Support CC1/CC2 test, D+D-voltage monitoring

· Support LAN, RS485 communication control

· Current rise/fall rate can be set, voltage loop response speed adjustable​
